Installation Manual 70 Document #: LTRT-94704
Mediant 3000 & IPmedia 3000
d. Ease the blade all the way into the slot, using your thumbs until the
ejector/injector latches touch the chassis and the blade is flush with the chassis
slot.
Note:
Do not use excessive force when inserting the blade into the chassis cage.
e. Lock the blade into place by pressing the two black ejector/injector latches on
both ends inward, toward the middle, until you hear a click.
f. Using a Philips screwdriver, fasten the screws located at both ends of the blade to
secure it to the chassis and to ensure that it has an earth connection to the
chassis.
g. If the device is in Simplex mode, perform the following: power on the device and
then unlock the device using the device's Embedded Web Server (refer to the
device's User's Manual) or EMS management system. Unlock parameters, also
known as node maintenance are also provided using an SNMP interface (refer to
the Product Reference Manual).
h. Update the MAC address (if managing the blade with the EMS) and IP address (if
necessary) of the replacement blade.
i. Load the backup ini files and other configuration files to the device (refer to the
device's User's Manual).
¾ To replace an RTM:
1. Remove the RTM from the chassis, by performing the following:
a. Gracefully lock the device using the device's Web interface (refer to the device's
User's Manual) or EMS management system, and then power down the device.
Graceful shutdown can also be initiated using an SNMP interface using the 'node
maintenance' parameters (refer to the Product Reference Manual).
b. Disconnect all cables.
c. Using a Philips screwdriver, unfasten the screws located at both ends of the RTM
that secure it to the chassis.
d. Press the RTM's red ejector buttons on each of the two black ejector/injector
latches to release the RTM from the slot.
e. Simultaneously rotate the ejector/injector latches outward to disengage the RTM
from the slot.
f. Pull on the two ejector/injector latches and gently slide the RTM out of the slot.
2. Insert the replacement RTM, by performing the following:
a. Choose the appropriate slot in the compactPCI™ chassis.
b. Ensure that the RTM's red ejector buttons on each of the two black ejector/injector
latches are pressed-in (i.e., black ejector/injector latches in the open, pulled out
position).
c. Hold the RTM horizontally and insert it into the slot, aligning its edges with the
groves inside the slot.
