5.5.8 Configuring the Endpoint Settings
The Endpoint Settings screens enable you to configure port-specific parameters.
5.5.8.1 Authentication
The Authentication Table (normally used with FXS gateways) defines a username and password
combination for authentication for each MediaPack port.
The ‘Authentication Mode’ parameter (described in Table
5-2) determines if authentication is
performed per port or for the entire gateway. If authentication is performed for the entire gateway,
this table is ignored.
Note that if either the username or password field is omitted, the port’s phone number (defined in
Table 5-18) and global password (refer to the parameter ‘Password’ described in Table
5-2) are
used instead.
¾ To configure the Authentication Table, take these 6 steps:
1. Set the ‘Authentication Mode’ parameter to ‘Authentication per Endpoint’.
2. Open the ‘Authentication’ screen (Protocol Management menu > Endpoint Settings >
Authentication option); the ‘Authentication’ screen is displayed.
Figure
5-21: Authentication Screen
3. In the ‘User Name’ and ‘Password’ fields for a port, enter the username and password
combination respectively.
4. Repeat step 4 for each port.
5. Click the Submit button to save your changes.
6. To save the changes so they are available after a power fail, refer to Section
5.9 on page
161.
Table
5-20: Authentication ini File Parameter
Parameter Name in ini File Parameter Format
Authentication_x
Authentication_<Port Number
> = <Username>,<Password>
For example:
Authentication_0 = david,14325
Authentication_1 = Alex,18552
Note: Using the sign ‘$$’ enables the user to omit either the username or
the password. For instance, Authentication_5 = $$, 152. In this case,
endpoint 5’s phone number is used instead of username.
