Table 3-3: MP-104/FXS Lifeline Setup Component Descriptions
Item # Component Description
1
B: To PSTN wall port.
2
Phone to Port 1.
3
Lifeline to Port 4.
4
PSTN to Splitter (B).
5
Phone to Port 1.
6
Lifeline phone to Splitter (A).
7
Lifeline phone.
