AudioCodes MediaPack MP-112 User Manual

MediaPack SIP
MediaPack SIP User’s Manual 90 Document #: LTRT-65405
Table 5-14: Reasons for Alternative Routing ini File Parameter
Parameter Name in ini File Parameter Format
AltRouteCauseTel2IP
AltRouteCauseTel2IP = <SIP Call failure reason from IP>
For example:
AltRouteCauseTel2IP = 408 (Response timeout).
AltRouteCauseTel2IP = 486 (User is busy).
Note: This parameter can appear up to 4 times.
AltRouteCauseIP2Tel
AltRouteCauseIP2Tel = <Call failure reason from Tel>
For example:
AltRouteCauseIP2Tel = 3 (No route to destination).
AltRouteCauseIP2Tel = 17 (Busy here).
Note: This parameter can appear up to 4 times.

AudioCodes MediaPack MP-112 Specifications

General

Fax Support	T.38, G.711 pass-through
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% non-condensing
Ports	2 FXS
Network Interface	10/100Base-T Ethernet
Protocols	SIP, MGCP
Voice Codecs	G.711, G.723.1, G.726, G.729A/B
Management	Web, SNMP
Power Supply	12V DC
