MediaPack SIP
MediaPack SIP User’s Manual 98 Document #: LTRT-65405
Table 5-18: Endpoint Phone Numbers Table
Parameter Description
Hunt Group ID In each of the Hunt Group ID fields, enter the hunt group ID (1-99) assigned to the
channel(s). The same hunt group ID can be used for more than one channel and in
more than one field.
The hunt group ID is an optional field that is used to define a group of common behavior
channels that are used for routing IP to Tel calls. If an IP to Tel call is assigned to a hunt
group, the call is routed to the channel or channels that correspond to the hunt group ID.
You can configure the Hunt Group Settings table to determine the method in which new
calls are assigned to channels within the hunt groups (refer to Section
5.5.7 on page
99).
Note: If you enter a hunt group ID, you must configure the IP to Hunt Group Routing
Table (assigns incoming IP calls to the appropriate hunt group). If you do not configure
the IP to Hunt Group Routing Table, calls don’t complete.
For information on how to configure this table, refer to Section
5.5.4.3.
Profile ID Enter the number of the Tel profile that is assigned to the endpoints defined in the
‘Channel(s)’ field.
Parameter Name in ini File Parameter Format
TrunkGroup_x
TrunkGroup_<Hunt Group ID> = <Starting channel> - <Ending channel>, <Phone
Number>, <Tel Profile ID>
For example:
TrunkGroup_1 = 1-4,100
TrunkGroup_2 = 5-8,200,1
Note 1: The numbering of channels starts with 1.
Note 2: ‘Hunt Group ID’ can be set to any number in the range 1 to 99.
Note 3: When ‘x’ (Hunt Group ID) is omitted, the functionality of the TrunkGroup
parameter is similar to the functionality of ChannelList and Channel2Phone parameters.
Note 4: This parameter can appear up to 8 times for 8-port gateways and up to 24 times
for MP-124 gateways.
Note 5: An optional Tel ProfileID (1 to 4) can be applied to each group of channels.
ChannelList
Note: TrunkGroup_x
parameter can be used
instead.
List of phone numbers for MediaPack channels
a, b, c, d
a = first channel.
b = number of channels starting from ‘a’.
c = the phone number of the first channel.
d = Tel Profile ID assigned to the group of channels.
For example: ChannelList = 0,8,101, defines phone numbers 101 to 108 for up to 8
channels.
Note 1: The ini file can include up to 24 ‘ChannelList‘ entries.
Note 2: The ‘ChannelList’ can be used instead of, or in addition to, Channel2Phone
parameter.
Channel2Phone
Phone number of channel.
Its format: Channel2Phone = ‘<channel>, <number>’
<channel> is 0...23.
Example: ‘Channel2Phone = 0, 1002’
Appears once for each channel: 8 times for 8-port gateways, or 4 times for 4-port
gateways and twice for 2-port gateways.
For 8-port and 24-port gateways it is suggested to use ‘TrunkGroup’ parameter, where
in a single line, all gateway’s phone numbers can be defined.
Note: When ‘Channel2Phone’ is used to define an endpoint, hunt group and profile can’t
be assigned to that endpoint.
