Please state device type and our order number (see name plate) when ordering spare parts. Only original AUMA spare parts should be used.
Failure to use original spare parts voids the warranty and exempts AUMA from any liability. Representation of spare parts may slightly vary
from actual delivery.
TypeDesignationRef. no.TypeDesignationRef. no.
Sub-assemblyScrew plug539.0Sub-assemblyHousing001.0
Sub-assemblyHandwheel with ball handle542.0Sub-assemblyBearing flange002.0
Sub-assemblyOutput drive types B/B1/B2/B3/B4/C/E549.0Sub-assemblyHollow shaft003.0
Sub-assemblyOutput drive sleeve B/B1/B2/B3/B4/C/E549.1Sub-assemblyDrive shaft005.0
Parallel key551.1Motor coupling005.1
Sub-assemblyMechanical position indicator553.0Manual drive coupling005.3
Sub-assemblySocket carrier for motor plug/socket con-
nector with cable harness
554.0Worm wheel006.0
Sub-assemblyPotentiometer as position transmitter556.0Sub-assemblyManual gearing009.0
Sub-assemblyPotentiometer without slip clutch556.1Sub-assemblyTorque lever017.0
Heater557.0Gear segment018.0
Sub-assemblyBlinker transmitter including pins at wires
(without impulse disc and insulation plate)
558.0Crown wheel019.0
Sub-assemblyElectromechanical control unit with
switches, including torque switching heads
559.0-1Sub-assemblyDrive pinion II for torque switching022.0
Sub-assemblyElectronic control unit with magnetic limit
and torque transmitter (MWG)
559.0-2Sub-assemblyOutput drive wheel for limit switching023.0
Sub-assemblySwitch stack for direction OPEN560.0-1Sub-assemblyDrive wheel for limit switching024.0
Sub-assemblySwitch stack for direction CLOSE560.0-2Sub-assemblyLocking plate025.0
Sub-assemblySwitch for limit/torque560.1Sub-assemblyCable for protective earth058.0
Switch case560.2Sub-assemblyMotor (only for V... motors incl. ref. no.
079.0)
070.0
Sub-assemblyRWG position transmitter566.0Sub-assemblyPlanetary gearing for motor drive (only for
V... motors)
079.0
Sub-assemblyPotentiometer for RWG without slip clutch566.1Sub-assemblyReduction gearing155.0
Sub-assemblyPosition transmitter board for RWG566.2Sub-assemblyCover500.0
Sub-assemblyCable set for RWG566.3Sub-assemblySocket carrier (complete with sockets)501.0
Sub-assemblySlip clutch for potentiometer567.1Sub-assemblyPin carrier without pins502.0
Stem protection tube (without cap)568.1Sub-assemblySocket for controls503.0
Protective cap for stem protection tube568.2Sub-assemblySocket for motor504.0
V-seal568.3Sub-assemblyPin for controls505.0
Threaded sleeve568.4Sub-assemblyPin for motor506.0
Stem nut A (without thread)575.1Sub-assemblyCover for electrical connection507.0
Sub-assemblyMotor coupling on motor shaft583.0Sub-assemblyThreaded plug511.0
Pin for motor coupling583.1Sub-assemblyOutput drive type A (without stem nut)514.0
Sub-assemblyRetaining spring for motor coupling584.0Sub-assemblyAxial needle roller bearing514.1
Sub-assemblyEWG position transmitter614.0Radial seal for output drive type A514.2
MWG 05.03 cover627.0Sub-assemblyOutput drive type D516.0
SetSeal kit, smallS1Output drive shaft D516.1
SetSeal kit, largeS2Snap ring535.1
86
SA 07.2 – SA 16.2/SAR 07.2 – SAR 16.2 Control unit: electronic (MWG)
Spare parts AC 01.2 Non-Intrusive HART
