Information For "SIL seating" = "forced limit seating in end position", the seating is performed
via limit switches in the end position. Since each switch has a hysteresis, the actuator
leaves the end position prior to limit switch release. Consequently, there is a marginal
range of actuator positions to the safety position, for which the limit switch is still
operated when leaving the safety position while the Safe ESD function is NOT
available. In this case, safety function triggering leads to actuator standstill. If the
range in question is approached from the opposite direction, this limitation does not
apply. In general this range is relatively low. However, for unfavourable configurations
(low number of turns per stroke), this range can amount to more than 10 % of the
total stroke.
Should within the framework of unfavourable conditions the effect described above
represent an unacceptable limitation for the safety function, we recommend applying
the configuration "forced torque seating in end position" or "no seating" for safety
operation.
Power supply
Information The plant operator is responsible for power supply.
3.2. Configuration (setting)/version
Configuration (setting) of safety-related functions is adjusted in the factory during
controls assembly and validated during final inspection. Subsequent modification of
the configuration by the plant operator is not permissible.
General functions are set as described in the Operation instructions or the Manual
(Operation and setting) AUMATIC AC 01.2.
Configuration of safety-related functions is listed in the order-related technical data
sheet.
Configuration options for safety function
Table 3: Configuration options for safety function
Short descriptionConfiguration
SIL function
Safe CLOSINGSafe ESD CLOSE/CLOSE
Safe OPENINGSafe ESD OPEN/OPEN
Safe STOP in direction CLOSE and direction OPENSafe STOP CLOSE/OPEN
Safe CLOSING and Safe STOP in direction CLOSE
and direction OPEN
Safe ESD CLOSE/CLOSE + Safe
STOP CLOSE/OPEN
Safe OPENING and Safe STOP in direction CLOSE
and direction OPEN
Safe ESD OPEN/OPEN + Safe
STOP CLOSE/OPEN
Seating configuration options
Information Seating of standard actuator controls should be configured as set forth in the tables
below.
8
Multi-turn actuators
Architecture, configuration and applications SA 07.2 – SA 16.2/SAR 07.2 – SAR 16.2
