3.6 Finishing Installation
STEP 1
Push the main unit onto the wire box. Ensure
they are securely attached.
STEP 2
Install and tighten the four M1/5” (5 mm) x
2/5” (10
mm) screws using the T25 Torx
screwdriver to secure the charger.
STEP 3
Instal
l the four screw plugs. Ensure the
contact pins fit the contacts in the main unit.
The installation is now completed.
