4.7 LED Descriptions
LED Descriptions
Color Light Description
Yellow
Solid Yellow
The charger is not activated.
The charger is disabled after being activated.
Flashing Yellow The charger is being activated.
Streaming Yellow Batch configuration status.
Breathing Yellow The charger is upgraded.
Green Solid Green The charger is available.
Blue
Solid Blue
The connector is plugged into an EV and the charger waits
for authentication.
An EV finishes charging and the connector waits for being
unplugged.
Breathing Blue Charging status.
Red Solid Red
Malfunction status.
The charger is unavailable.
Cyan
Solid Cyan The charger has been reserved.
Cyan light flashes three
times.
The charger’s hotspot is opened manually.
