21
N415A
When using the diagnostic functions, use the Table of Zones to see what input has triggered the system. It is also
helpful in deciding what input to use when connecting optional sensors and switches
Zone # Trigger Type Input Description
One Instant H1/6 BLUE wire. Connect to optional
hood/trunk pins
Two Mutiplexed Heavy impact detected by the on-board
dual-stage shock sensor.
Three Two-stage, progresses from Door switch circuit. H1/5 GREEN or H1/7
warning to full alarm VIOLET.
Four Multiplexed Optional sensor, BLUE and GREEN wires
on the 4-pin sensor plug.
Five Two-stage (similar to doors) Ignition input. H1/9 YELLOW.
The warn away response does not report on the LED.
TABLE OF ZONES
