Auto Mate 415 User Manual

8
N415A
H1/1
H1/2
H1/3
H1/4
H1/5
H1/6
H1/7
H1/8
H1/9
H1/10
H1/11
H1/12
ORANGE (-) 500 mA ARMED OUTPUT
WHITE (+)/(-) SELECTABLE LIGHT FLASH OUTPUT
WHITE/BLUE (+) TRUNK RELEASE INPUT,SENSOR BYPASS
BLACK/WHITE (-) 200 mA DOMELIGHT SUPERVISION OUTPUT
GREEN (-) DOOR TRIGGER INPUT, ZONE 3
BLUE (-) INSTANT TRIGGER INPUT, ZONE 1
VIOLET (+) DOOR TRIGGER INPUT, ZONE 3
BLACK (-) CHASSIS GROUND INPUT
YELLOW (+) SWITCHED IGNITION INPUT, ZONE 5
BROWN (+) SIREN OUTPUT
RED (+) CONSTANT POWER INPUT
RED/WHITE (-) 200 mA CHANNEL 2 OR DELAYED ACC.OUTPUT
PRIMARY HARNESS H1, 12-PIN CONNECTOR

Auto Mate 415 Specifications

General

Brand	Auto Mate
Model	415
Category	Car Alarm
Language	English
