SE6166 Controller • Rev. 4/13/2011 21 © 2011 Automated Logic Corporation
5 Type the computer's Port number that the USB cable is connected to.
NOTE To find the port number, plug the USB cable into the computer's USB port, then
select
Start > Control Panel > System > Hardware > Device Manager > Ports (Com &
LPT). The COM port number is beside CP210x USB to UART Bridge Controller.
6 Set the Baud rate to 115200.
7 Click OK.
8 On the View tab, click the drop-down arrow next to your device's network Connection,
then select
BACnet Local Access.
9 Click OK.
10 On the Configure tab, select BACnet Local Access, then click Start.
NOTE If WebCTRL displays an error, make sure the COM port you selected is not in
use. For example, PuTTY may be open and is holding the port open.
11 On the NET tree, select the controller that you are connected to.
12 Click the menu button , then select Manual Command.
13 Type rnet here in the dialog box, then click OK.
14 On the Properties page, click Module Status. If WebCTRL displays a Modstat report,
WebCTRL is communicating with the controller.
If you have problems mounting, wiring, or addressing the SE6166, contact ALC Technical
Support.
If you cannot communicate with a controller after downloading it, as a last resort, you can
manually format the controller to erase its memory.
1 Turn off the SE6166's power. Make sure the address switches are not set to 0, 0.
2 Hold down the controller’s Format button while you turn its power on.
3 Continue to hold down the Format button until the Error LED stops flashing and turns
on, then release the button.
4 Download the SE6166.
Formatting the
controller
