SE6166 Controller • Rev. 4/13/2011 1 © 2011 Automated Logic Corporation
The SE6166 controller controls rooftop Air Handling Units (AHUs) or other large single
pieces of equipment. You can mount the SE6166 on or inside the rooftop equipment.
Driver DRV_SE
Maximum number of control programs 1
Maximum number of BACnet objects* 300**
* Depends on available memory.
** Any points that exceed this number will not be network visible.
Power 24 Vac ±10%, 50–60 Hz, 20 VA power consumption (38.4
VA with BACview6 attached) single Class 2 source only, 100
VA or less
BACnet port
(This port may be labeled
CMnet.)
For communication with the controller network using
ARC156 or MS/TP (9600 bps–76.8 kbps)
Local Access port For system start-up and troubleshooting
LogiStat port For LogiStat and LogiStat Plus room sensors. The LogiStat
port uses two universal inputs.
The SE6166 does not support the LogiStat Pro. Use
an RS Pro on the Rnet port instead.
Rnet port Supports up to four RS Standard sensors and one RS Plus,
RS Pro, or RS Pro-F sensor for averaging or high/low select
control. The sensors can share the Rnet port with a BACview
5
or BACview
6
.
If you use the Rnet port, you cannot connect a
LogiStat sensor to the LogiStat port.
Inputs 16 inputs, configurable for 0–10 Vdc, 0–20 mA, RTD,
thermistor, or dry contact, and one LogiStat port. Inputs 1
and 2 are also configurable for pulse counter or timed local
override (TLO).
If using a LogiStat or LogiStat Plus, temperature and
setpoint adjust inputs replace inputs 9 and 10, making 9
and 10 unavailable.
Input resolution 12 bit A/D
Input pulse frequency 40 pulses per second. Minimum pulse width (on or off time)
required for each pulse is 12.5 msec.
Digital outputs 6 digital outputs, relay contacts rated at 3 A max @ 24 Vac.
Configured normally open.
What is the SE6166 controller?
Driver and control
program
Specifications
