Automated Logic SE6166 User Manual

SE6166 Controller • Rev. 4/13/2011 23 © 2011 Automated Logic Corporation
If you need the SE6166's serial number when troubleshooting, the number is on:
• a sticker on the back of the main controller board
• a Module Status report (Modstat) under Core (or Main) board hardware
To obtain a modstat in WebCTRL:
1 Select the SE6166 in the NET tree.
2 On the Properties page, click Module Status.
The SE6166's 10-year Lithium CR2032 battery provides a minimum of 10,000 hours of
data retention during power outages.
If the SE6166 sends a Low Battery alarm to WebCTRL, replace the battery.
1 Remove the battery from the controller, making note of the battery's polarity.
2 Insert the new battery into the controller, matching the polarity of the battery you
removed.
3 Download the SE6166.
If needed for troubleshooting or start-up, you can prevent WebCTRL Server from
communicating with the SE6166.
1 Select the SE6166 in WebCTRL's NET tree.
2 On the Properties page, select the Out of Service checkbox.
3 Click OK.
Serial number
Replacing the
SE6166's
battery
To take the
SE6166 out of
service

Automated Logic SE6166 Specifications

General

Brand	Automated Logic
Model	SE6166
Category	Controller
Language	English
