SE6166 Controller • Rev. 4/13/2011 2 © 2011 Automated Logic Corporation
Analog outputs 6 analog outputs, 0–10 Vdc or 0–20 mA selectable
Output resolution 8 bit D/A
Microprocessor High speed 16-bit microprocessor with ARCNET
communication co-processor
Memory 1 MB non-volatile battery-backed RAM, 1 MB Flash memory,
16-bit memory bus
Real-time clock Battery-backed real-time clock keeps track of time in event
of power failure
Battery 10-year Lithium CR2032 battery provides a minimum of
10,000 hours of data retention during power outages
Protection Incoming power and network connections are protected by
non-replaceable internal solid-state polyswitches that reset
themselves when the condition that causes a fault returns to
normal. The power, network, input, and output connections
are also protected against voltage transient and surge
events.
BT485 connector You attach a BT485 (not included) to a controller at the
beginning and end of a network segment to add bias and to
terminate a network segment.
Status indicators LED's indicate status of communications, running, errors,
power, and digital outputs
Environmental operating
range
-20 to 140°F (-29 to 60°C), 10–90% relative humidity, non-
condensing
The controllers should be mounted in a protective
enclosure.
Physical Rugged aluminum cover, removable, screw-type terminal
blocks
Overall dimensions Width:
Height:
8 5/16 in. (21.1 cm)
7 in. (17.8 cm)
Mounting dimensions Width:
Height:
7 7/8 in. (19.9 cm)
5 in. (12.7 cm)
Recommended panel
depth
1 1/2 in. (3.8 cm)
Weight 1.2 lbs (0.5 kg)
BACnet support Conforms to the Advanced Application Controller (B-AAC)
Standard Device Profile as defined in ANSI/ASHRAE
Standard 135-2004 (BACnet) Annex L
Listed by UL-916 (PAZX), cUL-916 (PAZX7), FCC Part 15-Subpart B-
Class A, CE EN50082-1997
