ZoneLogix™ PRO Branch Monitor Guide | Revision 0.1 September 2019 | Page 35

A.3.

ZIP

Figure 23: ZIP (Operating Mode)

Zone 3 will have permission to release Package 2 into Zone 2 once Package 1 has hit zone 2 sensor.

A.4.

Zone Hold

Figure 24: Zone Hold (Singulate, ZIP, and Slug Modes)

If Zones 2 and 3 were put into Zone Hold, Package 2 will be held in Zone 3 when it is detected by the Zone 3 sensor.

Zone 2 would attempt to hold Package 1, however depending on Package 1 position at the time it may be pulled into

Zone 1.
