Addressing Panels
Commissioning Handbook, AutroSafe Interactive Fire Detection System, Release 4, 116-P-ASAFE-COMMISS/EGB Rev.F, 2014-04-01,
Autronica Fire and Security AS
Page 17
6.2 Location of Switches
The switches are located on the lower left hand side of the BSA-400
circuit board, easily accessible through the hole in the metal cover.
The BSA-400 circuit board
