Autronica AUTROSAFE 4 User Manual

Addressing Panels
Commissioning Handbook, AutroSafe Interactive Fire Detection System, Release 4, 116-P-ASAFE-COMMISS/EGB Rev.F, 2014-04-01,
Autronica Fire and Security AS
Page 20
Example:
A network configuration consists of two BS-420 panels, one BS-430
panel and one BU-BV-420 panel (a BU-BV-420 panel defined as a
Fire Brigade Panel).
In this example, the following addressing applies:
Panel
Panel ID
Rotary
switch X6
Rotary
switch X4
Panel Type
Dip-switch S2
0=OFF, 1=ON
Switch 1 2 3 4
BS-420
1
0
1
0 0 0 0
BS-420
2
0
2
0 0 0 0
BS-430
65
0
1
0 1 0 0
BU-BV-420
97
0
1
1 1 0 0
