Avant e5
54
.
Tie down options
Optional equipment for frequent trailer transport
If transporting the loader frequently on a trailer,
optional tie down brackets are available for easier
securing of load.
Tie down bracket A418623 installed at the rear
bumper or counterweight
Tie down bracket A418623 installed at the side of
rear frame
For side installation, two brackets are needed.
Tie down bracket on wheel hub A421206
.
Lifting
The loader can be lifted by mounting appropriate
lifting slings on the ROPS frame. Lifting kit A418706
includes all necessary parts to lift the loader, contact
your dealer.
Before lifting, heavy attachment and possible extra
weights must be removed. Mount the frame lock on
the machine.
Make sure that the lifting slings cannot move and
that the machine doesn't swing during lifting. Loop
the lifting straps around all four ROPS posts and
make sure they are not tied or get damaged by e.g.
sharp corners. Follow the instructions given in the
operator’s manual of the lifting slings. To lift a loader
that is equipped with the Cab L, the front, side, and
rear window panels must be removed first.
Lower the boom and mount the
articulation frame lock, see page
72. Remove any heavy attachment
and extra counterweights before
lifting. Never lift a loader with
persons riding the machine.
