Avantik Cryostat QS11 / QS11UV
Avantik
36 Commerce St.
Springfield NJ 07081 / USA
387 779 - English
12
page -2-
VU11SQ / 11SQ ATAD LACINHCET 2-1
Handwheel brake: ..................................................................................... mechanical
Transportation and storage conditions
Storage temperature range: ........................................................................ -20°C up to +50°C
Operating conditions: ........................ +5°C up to +35°C (at a max. rel. humidity of 60%)
itla .......................................................... tude up to 2000 m M.S.L.
i rof .......................................................................... ndoor use only
roolF .......................................... loading requirements: 230 kg/m
2
Power requirements: ............................................................ 100 V/50 Hz, 12 A, +/-10%
zH 06/V 001 ............................................................. , 12 A, +/-10%
zH 06/V 511 ............................................................. , 12 A, +/-10%
05/V 032...022 ...................................................... Hz, 6 A, +/-10%
zH 06/V 022 ............................................................... , 6 A, +/-10%
zH 05/V 042 ............................................................... , 6 A, +/-10%
Internal protection
Primary circuits:
Transformer: ....................................................................... T5.0AH, 100...115 V
5.2T ....................................................................... AH, 220...240 V
Illumination: ....................................................................... T0,8AH, 100...115 V
4,0T ....................................................................... AH, 220...240 V
Secondary circuits:
Window heating: ........................................................................................... T2,5AH
CPU: .............................................................................. 11 VAC/T0.5AH
Panel: .............................................................................. 11 VAC/T0.5AH
Stepping motor/valve: .............................................................................. 24 VAC/T2.5AH
Fast freezing station: .......................................................................... 2.3/8 VAC/T8.0AH
Pollution degree: ...................................................................................................... 2
Overvoltage category: ...................................................................................................... II
Sound pressure: ......................................................................................... 45 dB(A)
............................... measured with 1 m distance to the instrument
Fluids and gases: .................................................................... cooling agent: R404a,
illif ................................................... ng amount: 100...120 V: 250 g
...022 .......................................................................... 240 V: 230 g
Dimensions: .. Wide (w/o handwheel): 640 mm, deep: 760 mm, high: 1200 mm
Weight: ................................................... 143 kg (depending on the model)
All temperatures refer to an ambient temperature of +20°C!
