2-7-3 DISPOSABLE BLADE CARRIER EC 70
The disposable blade carrier EC takes up all commercially available low profile blades with a
dimension of 80 x 8 mm and a facette angle of approx. 35° and as another version it takes also up
high profile blades. The anti-roll plates have a length of 69,5 mm.
Fig. 24a
9 1
2
3
4
5
6
7
8
10
11
