Avantik Cryostat QS11 / QS11UV
Avantik
36 Commerce St.
Springfield NJ 07081 / USA
387 779 - English
40
Caution:
To avoid the danger of injury on the
blade during adjustment of specimen,
always position the knife guards (fig.
24a.7) over the blade edge.
Fine adjustment of the anti-roll device:
• The fine adjustment of the anti-roll plate is
carried out via the knurled screw (fig.
24a.6).
Note:
Insert the glass anti-roll plate parallel
towards the blade edge.
Selecting the clearance angle:
• Loosen the clamping lever (fig. 24a.3).
• Swivel the upper part of the blade carrier on
the base until the desired clearance angle
is reached.
• The clearance angle can be read on the
scale (fig. 24a.4) on the left side on the
base.
• Bring the clamping lever (fig. 24a.3) into
clamping position.
• The selected clearanc
e angle is now fixed
in
its position.
Note:
Usable cuts are only achieved at a
clearance angle of 10° or more!
