44
RX / TX TEST
In the RX/ TX test the VSI-Pro echos whatever it receives. Press the “Up” or “Down” button to move the cursor to “RX/
TX TEST” and press “Set”. The following display will appear (example only):
VSI-Pro VIDEO SERIAL INTERFACE
Figure 73: RX /TX TEST Display
Press “Set” to return to the previous menu.
BAUD RATE SCAN
The Baud Rate Scan test can scan the baud rate of your register. Press the “Up” or “Down” button to move the cursor
to “BAUD RATE SCAN” and press “Set”. The following display will appear (example only):
Enter a transaction from the register. The VSI-Pro will detect the baud rate and display it in front of RX Baud rate.
Press “Set” to return to the previous menu.
EXIT
Press the “Up” or “Down” button to move the cursor to “EXIT” and press “Set” to return to the previous menu.
Figure 74: Baudrate Scan Display
RX BAUDRATE : AUTO
TX BAUDRATE : 2400
PARITY : NONE
DATA BIT : 8
HANDSHAKING : OFF
ECHOING :
BAUDRATE DETECTION..
RX BAUDRATE : AUTO
TX BAUDRATE : 2400
PARITY : NONE
DATA BIT : 8
HANDSHAKING : OFF
BAUDRATE SCAN :
BAUDRATE DETECTION..
PROGRAMMING
NOTE ?
In any of the above tests, you can stop the scrolling data by holding down either “Up”
or “Down” button.
