VSI-Pro VIDEO SERIAL INTERFACE
SPECIFICATIONS
Table 4C : RS-485 Network Data Cable Wiring
Table 5C: Electrical Characteristics
Table 6C: Physical Characteristics
Table 7C: RS-232 Parameters
Table 8C: Network Parameters
RS-485 NETWORK DATA CABLE WIRING
RS-232 Parameters
Baud rate 9600
Data bits 8
Parity None
Stop bits 1
Physical Characteristics
Size 160 x 35 x 110 (mm)
Weight 300 g
Color Gray
Case material Plastic
Network Parameters
Standard RS-485
Max line length 4000 ft
Cable type 120 Ohm twised pair
Electrical Characteristics
Operating voltage 9-12V DC
Supply Current <200mA @ 12 V
Data Ports 1xRS-232 (DB-9), 2xRS-485 (RJ-
45)
(120 Ohm impedance, twisted pair)
RJ-45 RJ-45
Pin 4 Pin 4
Pin 5 Pin 5
APPENDIX C HYDRA and REGCOM
