Universal Slave Driver76
Rear Panel Connectors
Connector Specifications
LTC In Format: SMPTE/EBU 80-bit longitudinal, drop frame/non-
drop frame
Connector: 3-pin XLR female per IEC 268-12
Speed Range: 1/30 to 80X play speed, forward or backward
Level: -24 dBu to +9 dBu, differential (pin 2 hot)
Impedance: 200K ohms
LTC Out Format: SMPTE/EBU 80-bit longitudinal, drop frame/non-
drop frame
Connector: 3-pin XLR male per IEC 268-12
Speed Range: ±10% of play speed
Level: -24 dBu thru +9 dBu RMS, differential (pin 2 hot)
Level Default: 0 dBu RMS, 1.52V p-p ±10mV
Output Impedance: 5K ohms
Load Impedance (min): 600 ohms
Rise/Fall Time: 42us ± 1us measured between 10% and 90% p-p
S/N Ratio: -60 dB RMS at 0 dBu level
Video (Main) In Format NTSC or PAL composite video
Level: 1V p-p
Termination: 75 ohms
