Appendix B: Technical Specs 77
Video (Main) Out Level: 1V p-p
Source Impedance: 75 ohms
Video (Ref) In Format: NTSC or PAL composite video
Level: 1V p-p
Termination: 100K ohms
Video (Ref) Out Level: 1V p-p
Termination: 100K ohms
Description: Passive loop-thru of Video Ref in
AES Clock In Level: 5 V p-p at 110 ohms (pin 2 hot)
Connector: 3-pin XLR female per IEC 268-12
AES Clock Out Level: 5 V p-p at 110 ohms (pin 2 hot)
Connector: 3-pin XLR male per IEC 268-12
Word Clock In Level: 0 to .5 V (low), 2.0 to 6.0 V (high)
Connector: BNC Female
Word Clock Out Level: TTL (3.3 V typical)
Rear Panel Connectors
Connector Specifications
