Universal Slave Driver78
Connector: BNC Female
Super Clock In Level: 0 to .5 V (low), 2.0 to 6.0 V (high)
Connector: BNC Female
Super Clock Out Level: TTL (3.3 V typical)
Connector: BNC Female
Bi-phase/Tach/ Connector: 25-pin D-subminiature female (DB25)
GPI/Pilot
Bi-phase/Tach In Frequency Range: 0 to 76.8 KHz
Level: 4.5 to 5.5 V, opto-isolated
Current: 10 mA max
Polarity (bi-phase): Both inputs are software programmable
Polarity (tach): “Direction” polarity is software programmable
Modulo Range: 2 thru 254
Pilot In Level: 100 mV to 5.5 V p-p, differential
Frequency Range: 50/60 Hz nominal
Impedance: 200K ohms
Rear Panel Connectors
Connector Specifications
