Avigilon H5SL Series User Manual

l Camera's Web Interface: enter the camera's IPaddress in a web browser to access the web
interface. If the camera is in the factory default state you will be redirected to the Add a new user
page to create the first user. For more information, see the Avigilon High Definition H4 and H5 IP
Camera Web Interface User Guide.
l Camera Configuration Tool version 1.4.4 or later: cameras discovered in the factory default state will
be identified by . Select the Admin Users tab to create the first user. For more information, see
the Avigilon Camera Configuration Tool User Guide.
l USB Wi-Fi Adapter: when connecting a camera in the factory default state, you will be redirected to
the Create Administrator User page to create the first user. For more information, see Avigilon USB
Wi-Fi Adapter System User Guide.
l Avigilon Control Center software version 7.4 or later, or version 6.14.12 or later: when connecting a
camera in the factory default state, the client software will ask you to create a new user. For more
information, see the Avigilon Control Center Client User Guide.
l AvigilonCloud Services (ACS) v3.0 or later: when adding a camera you will be asked to create a new
user for cameras in the factory default state. For more information, see the AvigilonCloud Services
User Guide.
Tip: If you are connecting your Avigilon camera to a 3rd party VMS, you will need to set up the first
user through the camera's Web Interface, USB Wifi Adapter, or Camera Configuration Tool before
you connect to the 3rd party VMS.
(Optional) Using the USB Wi-Fi Adapter
If you have a USB Wi-Fi Adapter (H4-AC-WIFI), attach it to the camera's micro USB port to access the
camera's mobile web interface.
After you connect to the Wi-Fi signal broadcast by the adapter, you can access the mobile web interface
from any mobile device using the following address:
http://camera.lan
For more information about configuring the camera from the mobile web interface see Avigilon USB Wi-Fi
Adapter System User Guide.
Note: The camera will reserve the 10.11.22.32/28 subnet for internal use while the USB Wi-Fi
Adapter is plugged in.
Assigning an IP Address
The device automatically obtains an IP address when it is connected to a network.
(Optional) Using the USB Wi-Fi Adapter 11

Avigilon H5SL Series Specifications

General

Ingress Protection	IP66
Impact Rating	IK10
Day/Night	Yes, with IR cut filter
Wide Dynamic Range (WDR)	Yes, up to 120 dB
Video Compression	H.264, H.265, MJPEG
Ethernet	10/100BASE-T
Resolution	5 MP
IR Illumination	Yes
Operating Temperature	-40°C to 50°C (-40°F to 122°F)
Power	PoE, 12V DC
Sensor Type	CMOS
Lens Type	Fixed or varifocal
Iris	P-Iris
IR Distance	Up to 30m (98ft)
Frame Rate	Up to 30 fps
Analytics	Yes
Aperture	F1.6
Minimum Illumination	0 lux (IR on)
