Sharing a USB Printer
FRITZ!Box 7490 151
Suitable playback devices like TV sets, web radios,
smartphones and the Windows Media Player can then
call up the data from the media server for streaming.
Playback devices to be used in connection with the me-
dia server must support the UPnP AV standard. The term
“DLNA” is often used to designate this support.
Enable the “Media Server” function in the FRITZ!Box user
interface under “Home Network / Media Server”.
19.6 Sharing a USB Printer
You can connect a USB printer to the FRITZ!Box to make it
available to all participants in your home network.
Setting Up a USB Printer as a Network Printer
Connect the USB printer to the USB port of the FRITZ!Box.
Setting Up a USB Printer in Windows 7, Vista or XP
1. Click “Start / Control Panel” and select the printer cate-
gory of your operating system:
– “Devices and Printers” (Windows 7)
– “Printers” (Windows Vista)
– “Printers and Faxes” (Windows XP)
2. Click the printer icon with the right mouse button and se-
lect “Properties” or “Printer properties”.
3. Switch to the “Ports” tab.
4. Click “Add”.
5. Double-click the “Standard TCP/IP Port” entry and click
“New Port”, then “Next”.
6. Enter “fritz.box” in the “Printer name or IP address”
field.
If the printer is not displayed, you must first install the
printer drivers for this device. Consult the documenta-
tion of your printer for instructions.

AVM Fritz!Box 7490 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
USB version	3.2 Gen 1 (3.1 Gen 1)
Rack mounting	No
Frequency range	2.4 - 5 GHz
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
USB ports quantity	2
WLAN data transfer rates supported	450, 1300 Mbit/s
Ethernet LAN (RJ-45) ports	4
DHCP client	-
Security algorithms	WPA2, WPS
Power consumption (typical)	9.3 W
Product color	Red, Silver
Cables included	DC, LAN (RJ-45), Phone (RJ-11)

Weight and Dimensions

Depth	175 mm
Width	245 mm
Height	55 mm
Weight	- g
