AVM Fritz!Box 7490 User Manual

Connecting an IP Telephone
FRITZ!Box 7490 55
10.5 Connecting an IP Telephone
IP telephones are telephones for making calls over the Inter-
net and other computer networks.
If your FRITZ!Box 7490 is connected with a landline, you can
use the connected IP telephone to make calls over the land-
line network as well.
Connecting via LAN or Wireless LAN
1. Connect the IP telephone to the FRITZ!Box using a LAN
cable or wireless LAN.
The preconfigured wireless network key of the FRITZ!Box
is printed on the underside of the FRITZ!Box.
2. Configure the IP telephone in the FRITZ!Box; see
page 57.
10.6 Connecting a Door Intercom System
Door intercom systems with an a/b interface can be connect-
ed to the FRITZ!Box.
Read more in the FRITZ!Box Help:
1. Open the FRITZ!Box user interface, see page 32.
2. Click the Help button .
3. Enter “door intercom system” in the search field.

AVM Fritz!Box 7490 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
USB version	3.2 Gen 1 (3.1 Gen 1)
Rack mounting	No
Frequency range	2.4 - 5 GHz
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
USB ports quantity	2
WLAN data transfer rates supported	450, 1300 Mbit/s
Ethernet LAN (RJ-45) ports	4
DHCP client	-
Security algorithms	WPA2, WPS
Power consumption (typical)	9.3 W
Product color	Red, Silver
Cables included	DC, LAN (RJ-45), Phone (RJ-11)

Weight and Dimensions

Depth	175 mm
Width	245 mm
Height	55 mm
Weight	- g
