FRITZ!Box 7490 180
Cables
• Maximum power consumption: 27 W
• Average power consumption: 9.3 W
The average power consumption was determined at
room temperature (23 °C to 27 °C) with the following
load:
– DSL connection active
– wireless LAN on; no devices registered via wireless
LAN
– DECT on; one telephone registered via DECT; no ac-
tive calls
– one network device connected to a LAN port; no data
transfer; other LAN ports not in use
27.6 Cables
Network Cable (Yellow)
Illustration
Use
The network cable is used to connect computers and network devic-
es to the FRITZ!Box 7490.
• AVM recommends using a network cable no more than
100 meters long.
• Additional network cable is required if you would like to use all
of the FRITZ!Box 7490 network ports.
Extension
