AVM Fritz!Box 7490 User Manual

FRITZ!Box 7490 32
The FRITZ!Box User Interface
7The FRITZ!Box User Interface
The FRITZ!Box has a user interface you can open in a web browser on
your computer.
In the user interface you can set up the FRITZ!Box, enable or disable
functions and receive information on the FRITZ!Box and on your con-
nections.
7.1 Opening the User Interface
The FRITZ!Box user interface can be opened on any computer
connected with the FRITZ!Box.
1. Start a web browser on your computer.
2. Enter fritz.box
in the address line of the browser.
The FRITZ!Box user interface opens.
Entering the address fritz.box in the browser
If the user interface does not open, see the instructions on re-
solving errors in The User Interface Does Not Open from
page 161.
7.2 Overview: FRITZ!Box at a Glance
All important information about the FRITZ!Box is displayed di-
rectly on the “Overview” page of the FRITZ!Box user interface.
By clicking the linked entries or “more...” you can jump from
this page to the corresponding menus and configure settings
there.

AVM Fritz!Box 7490 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
USB version	3.2 Gen 1 (3.1 Gen 1)
Rack mounting	No
Frequency range	2.4 - 5 GHz
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
USB ports quantity	2
WLAN data transfer rates supported	450, 1300 Mbit/s
Ethernet LAN (RJ-45) ports	4
DHCP client	-
Security algorithms	WPA2, WPS
Power consumption (typical)	9.3 W
Product color	Red, Silver
Cables included	DC, LAN (RJ-45), Phone (RJ-11)

Weight and Dimensions

Depth	175 mm
Width	245 mm
Height	55 mm
Weight	- g
