Sharing a USB Printer
FRITZ!Box 7490 153
The USB printer has been configured and can be used as a
network printer.
Setting Up a USB Printer in Mac OS X version 10.5 or higher
1. In the dock, click “System preferences”.
2. Click “Print & Fax”.
3. Click the “+” sign.
4. Click “IP Printer”.
5. In the “Protocol:” drop-down list, select the entry “HP Jet
Direct – Socket”.
6. Enter “fritz.box” in the “Address:” input field.
7. In the “Print Using:” drop-down list, select the printer
that is connected to the USB port of your FRITZ!Box.
8. Click “Add”.
The USB printer has been configured and can be used as a
network printer.
If the FRITZ!Box is configured as a wireless repeater or
an IP client, enter here the IP address at which the
FRITZ!Box can be reached within the network.
If the printer is not displayed, you must first install the
printer drivers for this device. Consult the documenta-
tion of your printer for instructions.

AVM Fritz!Box 7490 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
USB version	3.2 Gen 1 (3.1 Gen 1)
Rack mounting	No
Frequency range	2.4 - 5 GHz
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
USB ports quantity	2
WLAN data transfer rates supported	450, 1300 Mbit/s
Ethernet LAN (RJ-45) ports	4
DHCP client	-
Security algorithms	WPA2, WPS
Power consumption (typical)	9.3 W
Product color	Red, Silver
Cables included	DC, LAN (RJ-45), Phone (RJ-11)

Weight and Dimensions

Depth	175 mm
Width	245 mm
Height	55 mm
Weight	- g
