Page #37 background imageLoading...
Page #37 background image
Using Energy-Saving Functions of the FRITZ!Box
FRITZ!Box 7490 37
Enabling Energy-Saving Mode for USB Hard Drives
In the FRITZ!Box you can enable an energy-saving function for
USB hard drives connected to the FRITZ!Box. When the
energy-saving function is enabled, connected USB hard
drives will be switched off when they are idle—as long as the
hard drives support the energy-saving function.
Enable the energy-saving function in the “Home Network /
USB Devices” menu in the FRITZ!Box user interface. You can
also test here whether your USB hard disk supports the ener-
gy-saving function.
Saving Energy at the LAN Ports
For energy-efficient use of your gigabit LAN ports you can
specify for each individual LAN port whether it should always
operate with full power (power mode) or with reduced energy
consumption (green mode). With green mode you can reduce
the power consumption of the FRITZ!Box to the level neces-
sary for your applications.
The LAN ports can be configured in the advanced view of the
FRITZ!Box user interface; see page 34. In the “Home Network
/ Network / Network Settings” menu you can select from
among the following operating modes in the “LAN Settings”
area:
Operating Mode Functionality and Power Consumption
Power Mode In this setting LAN connections are estab-
lished with a maximum throughput of
1Gbit/s.
Higher power consumption than in green
mode if the LAN port is used.
Green Mode As needed, the FRITZ!Box establishes LAN
connections with a data throughput rate of
100 Mbit/s.
Lower power consumption than for the “Power
Mode” setting.
