TELCO MODULE
ENG
Axel Technology srl www.axeltechnology.com TELCO MODULE
42
15.2.2 DESCRIPTION
Pins 8 and 9 are used to make RING LED on the Telco module panel blinking when a call is coming in (call signalling
may be also achieved via one or two ‘red light’ lamps connected to the two Power Supply relays see par. 15.3).
The remote interface photocoupler (pin 9 = Anode and pin 8 = Cathode) must be driven by an external suitable command
generated by external telephone hybrid. Typical current allowed: 5 mA (max 10 mA). Max voltage allowed: 15 V.
A + 15 VDC is provided on Pin 6 via a 470 Ohm resistor.
The Oxygen 5’s Hook optoinsulator closes whenever ‘Hook’ button is pressed. Typical current allowed: max 10 mA. Max
voltage allowed: 15 V.
It may be necessary to consult the hybrid manufacturer’s user manual in order to control its functions.
OXYGEN 5 Telco remote interface has been designed for direct connection to BOXTEL and MACROTEL 5 / 7 / 9 by
Axel Technology.
In particular, a regular, not crossed Pin to Pin 9 pole cable featuring standard RS232 connectors (i.e 9 pin serial
connection computer type) is required for BOXTEL connection.
