Introducing the xNode • 5
© 2016 Axia Audio - Rev 2.0
The home page will show system information.
Node ID: (shown if ID assigned): An xNode can be assigned an ID which is used to assist with IP addressing and
channel numbering.
Software Version: The code version which is used by the xNode.
Temperature: The temperature reading of the internal censor. Alarm status will appear if the temperature is above
acceptable limits.
Sync (in audio xNodes): Indication if the device is receiving sync from the network. A solid SYNC indication
represents synchronization with the network.
Net1 and 2: Status of the network ports and which is the active port.
Ofine Power and Power Over Ethernet: Status of power sources.
System Uptime: The amount of time since the last bootup.
From the Home page are links to other options. These links are covered in Chapter 3-8.
Using iProbe will allow a user to see all devices on the network. A left click on a device icon will enable the
user to open the conguration user interface (UI). This UI is presented on the screen of iProbe and is the
HTML interface as mentioned here. Authentication is the same through iProbe as with a web browser.
