Chapter Three:
The xNode in depth
This chapter covers details of the xNode family that are shared in common. The xNode is a 1U half-rack device that
can be mounted to a at surface or in an equipment rack with optional accessories.
All xNodes have a common user interface with settings for advanced conguration and maintenance..
Mounting
Optional Surface Mount kit
The optional surface mount kit (p/n 2011-00077) consists of two brackets that are used to secure the xNode to a
wall, under a desk, or almost any at surface.
The brackets secure to the side of the xNode, towards the front panel. There are four holes which are used for secur-
ing metal work to the xNode.
Figure 3-1
