Secure the bracket to the xNode with included screws in the desired conguration.
Figure 3-2 Outward conguration
Figure 3-3: Inward conguration
Optional Rack Mount kit
The optional rack mount kit (p/n 2011-00076) provides the ability to secure the xNode into an equipment rack.
Figure 3-4: Short rack ear
Figure 3-5: Long rack ear
