Axia xNode - DB-25 Connector Pinout

4: Analog xNode • 25
© 2016 Axia Audio - Rev 2.0
The pinout of the DB-25 connector follows established Pro Audio conventions. Breakout cables can be acquired
from your audio supply company.
The pinout of the DB-25
PIN FUNCTION
1 Channel 4b/8 +
2 Channel 4b/8 Gnd
3 Channel 4a/7 -
4 Channel 3b/6 +
5 Channel 3b/6 Gnd
6 Channel 3a/5 -
7 Channel 2b/4 +
8 Channel 2b/4 Gnd
9 Channel 2a/3 -
10 Channel 1b/2 +
11 Channel 1b/2 Gnd
12 Channel 1a/1 -
13 not used
14 Channel 4b/8 -
15 Channel 4a/7 +
16 Channel 4a/7 Gnd
17 Channel 3b/6 -
18 Channel 3a/5 +
19 Channel 3a/5 Gnd
20 Channel 2b/4 -
21 Channel 2a/3 +
22 Channel 2a/3 Gnd
23 Channel 1b/2 -
24 Channel 1a/1 +
25 Channel 1a/1 Gnd
