AXIS 223M - Setup Tools
Setup Tools
The AXIS 223M is configured from the setup tools, which are available from the link in the
web interface. The setup tools can be used by:
• Administrators, who have unrestricted access to all the Setup tools
• Operators, who have access to the Video & Image, Live View Config and Event
Configuration settings.
Accessing the setup tools from a browser
Follow the instructions below to access the Setup Tools from a browser.
1. Start your browser and enter the IP
address or host name of the camera
in the location/address field.
2. The Live View page is now
displayed. Click Setup to display the Setup tools.
Setup tools

Axis 223M Specifications

General

Megapixel	2 MP
Focal length range	4 - 8 mm
Maximum frame rate	12 fps
Maximum video resolution	1600 x 1200 pixels
Sensor type	CCD
Product color	Gray
Focus	1.4
I/O ports	RS-232 RS-485/422
Security features	Multi-level password, IP address filtering, HTTPS encryption.
Dimensions (WxDxH)	88 x 200 x 49 mm
Compliance industry standards	IEEE 802.1X, IEEE 802.11g/b

Weight and Dimensions

Weight	620 g
