AXIS 223M - Technical Specifications
Technical Specifications
Item Specification
Image sensor 1/2.7” Sony Wfine progressive scan RGB CCD
Lens • Computar HG2Z0414FC-MP-12
• F1.4 varifocal 4.0 –8.0 mm
• DC-iris
• C-mount.
• Focus range: 0.5 m to infinity
The camera can be used with C or CS mount lens.
Angle of view 38° - 72° horizontal
Zoom
Minimum illumination Color mode: 1.5 lux, F1.4
Black/white mode: 0.2 lux, F1.4
Video compression Motion JPEG
MPEG-4 Part 2 (ISO/IEC 14496-2), Profiles: ASP and SP
Resolutions • Motion JPEG: 29 resolutions from 1600x1200 to 160x120 via API, 18 selections via
configuration web page
• MPEG-4: 16 resolutions from 640x480 to 160x120 via API, 10 selections via
configuration web page
Frame rate • Motion JPEG:
Up to 12 fps at 1600x900 (16:9 resolutions)
Up to 9 fps at 1600x1200 (4:3 resolutions)
• MPEG-4:
Up to 12 fps at 640x360 (16:9 resolutions)
Up to 9 fps at 640x480 (4:3 resolutions)
Video streaming • Simultaneous Motion JPEG and MPEG-4
• Controllable frame rate and bandwidth
• Constant and variable bit rate (MPEG-4)
Image settings • Compression levels: 11 (Motion JPEG)/23 (MPEG-4)
• Rotation: 90º, 180º, 270º
• Configurable color level, brightness, sharpness, contrast, white balance, exposure
control, exposure area, backlight compensation, fine tuning of behavior at low light
• Overlay capabilities: time, date, text, privacy mask or image
Shutter time 2 s to 1/7500 s
Audio • Two-way (half duplex) or one-way.
• Requires external microphone input or line input.
• Mono audio output (line level) connects to PA system or active speaker with built-in
amplifier
• Audio compression: AAC LC 8/16 kHz sampling frequency, 8-64 kbit/s, G.711 PCM
64kbit/s, G.726 ADPCM 32 or 24 kbit/s
