AXIS 223M - Technical Specifications
Security • Multiple user access levels with password protection,
• IP address filtering,
• HTTPS encryption,
• IEEE 802.1X network access control
• User access log
Users 20 simultaneous users
Unlimited number of users using multicast (MPEG-4)
Alarm and event
management
• Events triggered by: video motion detection, active tampering, temperature limits, IR
cut filter, audio detection, external input, or according to a schedule, Image upload
over FTP, email and HTTP
• Notification over TCP, email, HTTP, and external output
• 36 MB of pre- and post alarm buffer
Connectors • RJ-45 for Ethernet 10BaseT/100BaseTX (PoE)
• Mini DC power jack
• Terminal blocks for 2 alarm inputs, 1 output, RS-485/422 half duplex port and
alternative power connection
• D-sub for RS-232 port
• 3.5 mm jack for Mic/Line in
• 3.5 mm jack for Line out
Casing Aluminum casing
Processors, memory • CPU: ETRAX FS
• Video processing and compression: ARTPEC-2
• RAM: 64 MB
• Flash: 8 MB
• Battery backed-up real-time clock
Power 7-24 V DC, max 6 W
10-24 V AC, max 8 VA
Power over Ethernet (IEEE 802.3af), Class 2
Operating conditions 0 - 50 °C (32 - 122 °F)
Humidity 20 - 80% RH (non-condensing)
Installation, management
and maintenance
• AXIS Camera Management tool on CD and web-based configuration
• Configuration of backup and restore
• Firmware upgrades over HTTP or FTP, firmware available at www.axis.com
Video access from
Web browser
• Camera live view
• Video recording to file (ASF)
• Sequence tour for up to 20 Axis video sources
• Customizable HTML pages
Minimum web browsing
requirements
• Pentium III CPU 500 MHz or higher, or equivalent AMD
• 128 MB RAM
• DirectX compatible graphics board,
• Direct Draw
• Windows Vista, XP, 2000, Server 2003,
• Internet Explorer 6.0 or later
• For other operating systems and browsers see www.axis.com/techsup
Item Specification
