AXIS 223M - System Options
Date & Time
Current Server Time - displays the current date and time (24h clock). The time can be
displayed in 12h clock format in the Overlay Images (see below).
New Server Time - Select your time zone from the drop-down list. If you want the AXIS
223M clock to automatically adjust for daylight savings time, select the Automatically
adjust for daylight saving time changes.
From the Time Mode section, select the preferred method to use for setting the time:
• Synchronize with computer time - sets the time from the clock on your
computer.
• Synchronize with NTP Server - the camera will obtain the time from an NTP
server every 60 minutes. Specify the NTP server's IP address or host name.
• Set manually - this option allows you to manually set the time and date.
Note:
Note that if using a host name for the NTP server, a DNS server must be configured under TCP/IP settings.
See Network > TCP/IP below.
Date & Time Format Used in Images - specify the formats for the date and time (12h or
24h) displayed in the Live View video streams.
Use the predefined formats or use your own custom date and time formats. See Advanced
File Naming & Date/Time Formats in the online help
for information on how to create
your own file formats.
Network - Basic TCP/IP Settings
IP Address Configuration
The AXIS 223M supports both IP version 4 and IP version 6. Both versions may be enabled
simultaneously, and at least one version must always be enabled.
When using IPv4, the IP address can be set automatically via DHCP, or a static IP address
can be set manually.
If IPv6 is enabled, your camera will receive an IP address according to the configuration in
the network router.
There are also options for setting up notification of changes in the IP address, and for
using the AXIS Internet Dynamic DNS Service. For more information on setting the IP
address, please see the online help.
Notes: • To receive notification whenever the camera’s IP address changes (via e.g. DHCP), configure the options for
notification of IP address change. See Services below.
• If your DHCP server can update a DNS server, you can access the AXIS 223M by host name which is always
the same, regardless of the IP address.

Axis 223M Specifications

General

Megapixel	2 MP
Focal length range	4 - 8 mm
Maximum frame rate	12 fps
Maximum video resolution	1600 x 1200 pixels
Sensor type	CCD
Product color	Gray
Focus	1.4
I/O ports	RS-232 RS-485/422
Security features	Multi-level password, IP address filtering, HTTPS encryption.
Dimensions (WxDxH)	88 x 200 x 49 mm
Compliance industry standards	IEEE 802.1X, IEEE 802.11g/b

Weight and Dimensions

Weight	620 g
