AXIS 223M - System Options
The authentication process
RADIUS
RADIUS (Remote Authentication Dial In User Service) is an AAA (Authentication,
Authorization and Accounting) protocol for applications such as network access or IP
mobility. It is intended to work in both local and roaming situations.
CA servers
In cryptography, a Certification Authority (CA) is an entity that provides signed digital
certificates for use by other parties, and thus acts a trusted third party.
There are many commercial CA’s that charge for their services. Institutions and
governments may have their own CA, and there are free CA’s available.
Protected network
Axis video device
Q: Certificate OK?
Certificate
Authority (CA)
3
1
2
4
A: OK
RADIUS
server
Network
switch
Q: Certificate OK?
A: OK
Certificate
Certificate
1. A CA server provides the required signed certificates.
2. The Axis video device requests access to the protected network at the network switch.
The switch forwards the video device’s CA certificate to the RADIUS server, which then
replies to the switch.
3. The switch forwards the RADIUS server’s CA certificate to the video device, which also
replies to the switch.
4. The switch keeps track of all responses to the validation requests. If all certificates are
validated, the Axis video device is allowed access to the protected network via a
pre-configured port.

Axis 223M Specifications

General

Megapixel	2 MP
Focal length range	4 - 8 mm
Maximum frame rate	12 fps
Maximum video resolution	1600 x 1200 pixels
Sensor type	CCD
Product color	Gray
Focus	1.4
I/O ports	RS-232 RS-485/422
Security features	Multi-level password, IP address filtering, HTTPS encryption.
Dimensions (WxDxH)	88 x 200 x 49 mm
Compliance industry standards	IEEE 802.1X, IEEE 802.11g/b

Weight and Dimensions

Weight	620 g
