AXIS 223M - Product Features
Network connector - The AXIS 223M connects to the network via a standard network
cable, and automatically detects the speed of the local network segment
(10BaseT/100BaseTX Ethernet). This socket can also be used to power the AXIS 223M via
Power over Ethernet (PoE). The camera also negotiates the correct power level when using
PoE.
Audio output - Audio output (line level), which can be connected to a public address (PA)
system or an active speaker with a built-in amplifier. A pair of headphones can also be
attached. A 3.5mm audio connector must be used for the audio out.
Audio input - One 3.5mm input for a mono microphone, or for line-in mono signal (only
the left channel is used from a stereo signal).
RS-232 connector - Single 9-pin D-SUB RS-232 connector, max 115 kbit/s, half-duplex.
Serial number - This number is used during installation.
Reset/Control button - Press this button to install the camera using the AXIS Internet
Dynamic DNS Service, or to restore the camera to its factory default settings, as described
in
Advanced, on page 48.
LED indicators - After completion of the startup and self test routines, the multi-colored
Network, Status, and Power LED indicators flash as follows:
LED Color Description
Network Green Steady for connection to 100 Mbit/s network. Flashes for network activity.
Amber Steady for connection to 10 Mbit/s network. Flashes for network activity.
Unlit No connection.
Note: The Network LED can be configured to be unlit during normal operation. See the online
help files for more information. Go to Setup > System Options > LED settings.
Status Green Shows steady green for normal operation.
Note: The Status LED can be configured to be unlit during normal operation, or to flash only
when the camera is accessed. See the online help files for more information. Go to Setup >
System Options > LED settings.
Amber Steady during startup, reset to factory default or when restoring settings.
Red Slow flash for failed upgrade.
Power Green Normal operation.
Amber Flashes green/amber during firmware upgrade.
