AXISA1001NetworkDoorController
•WireArea
-ULListedorR/CAWMwiresthathaveanconductorgaugerangeof
AWG22–14shallbeused.
-Theminimumconductorgaugeforconnectionbetweenthepowersourcing
equipment(PSE)orpowerinjectorandthepowereddevice(PD)is26AWG.
•Connectors
-ThisproductisnotintendedforoutsidewiringascoveredbyArticle800inthe
NationalElectricalCode,NFPA70.
-PowerConnector–ForULsecurityapplications,theproductshallbepowered
byaUL294ListedorUL603ListedClass2low-voltagepowerlimitedpower
supplythatiscapableof4hoursofstandbypower.
-NetworkConnector–PoweroverEthernet(PoE)shallbesuppliedbyaUL294
ListedClass2powerlimitedinjectorthatprovides44–57VDC,15.4Wand4
hoursofstandbypower.CompliancewithIEEE802.3(atoraf)specications
hasnotbeenveriedaspartofUL294/B.
-TamperingAlarmPinHeader–TocomplywithUL294/7.2.1(Enclosure),the
tamperingalarmshallbeconnectedtoasoundalarm.
•SystemConsiderations
-TheAxisproduct,whetheritisastandalonedoorcontrollerorasystemof
doorcontrollers,shallnotimpairtheintendedoperationofthepanichardware
usedinconjunctionwithit.
•WallandCeilingMount
-IfusingajunctionboxtomounttheAxisproduct,thejunctionboxshallbe
ULListed.
•AssignanIPAddress
-ThefunctionalityofAXISCameraManagement,seepage38,hasnotbeen
evaluatedbyUL.
•MaintenanceInstructions
-Formaintenanceinstructions(somestepsrequireaccesstotheproduct’s
webpages),seepage44.ForinformationabouthowtoconguretheAxis
productusingtheproduct’swebpages(AXISEntryManager),seetheUser
Manual.
•Furtherinformation
-Firmwareversion:DoorController,ModelA1001–1.20.2
8

Axis A1001 Specifications

General

Interface	RS-485
Built-in UPS	-
Maximum number of doors	2 door(s)
DC voltage range	10 - 30 V
Power consumption (typical)	26 W

Weight and Dimensions

Depth	45.3 mm
Width	180 mm
Weight	500 g
