AXIS M7014
System Options
For m ore information, see the online help .
IEEE 802.1X
IEEE 802.1X is a standard for port-based Network Admission Control providing secure authentication of wired and wireless network
devices. IEEE 802.1X is based on EAP (Extensible Authentication P rotocol).
To access a network protected by IEEE 802.1X, devices must authenticate themselves. The authentication is performed by a
third-party entity called an authentication server, typically a RADIUS server, examples of which are FreeRADIUS and Microsoft
Internet Authentication Service.
In Ax is ' implem entation, the network device and the authentication server authenticate themselves with the help of digital
certificates using EAP-TLS (Extensible Authentication Protocol - Transport Layer Security). The c ertificates are provided by an
Certification Authority (CA). You need:
•aCAcertificate to validate the identity of the authentication server
• a CA-signed c lie nt certificate and a private key to authenticate the network device.
To allow the network device to access a network protected by IEEE 802.1X:
1. Obtain a CA certificate, a client certificate and a client private key (contact your network administrator).
2. Go to Setup > System Options > Security > IEEE 802.1X and upload the CA certificate, the client certificate and the
client private key.
3. Under Settings, select the EAPOL version, provide your EAP identity and private key password.
4. Check the box to enable IEEE 802.1X and click Save.
Certificates
CA Certificate The CA certificate is used to validate the identity of the authentication server. Enter the path to
the certificate directly, or locate the file using the Browse button. Then click Upload.Toremove
acertificate, click Remove.
Client certificate
Client private k ey
The client certificate and private key are used to authenticate the network device. They can be
uploaded as se parate files or in one combined file (e.g. a PFX file or a PEM file). Use the Client
private key field if uploading one combined file. Fo r each file, e nter the path to the fi le, or locate the
file using the
Browse button. Then click Upload.Toremoveafile, click Remove.
Settings
EAPOL version
Select the EAPOL version (1 or 2) as u
sed in your network switch.
EAP identity
Enter the user identity (maximum 16 characters) associated with your certificate.
Private key password
Enter the passwo rd (maximum 16 characters) for the private key.
Enable IEEE 802.1X
Check the box t
o enable the IEEE 802.1X protocol.
Date & Time
The A
xis product’s date and time settings are configured under System Options > Date & Time.
Current Server Time displays the current date and time (24h clock). The time can be displayed in 12h clock in the text overlay (see
below).
To change the date and time settings, select the preferred Time mode under New Server Time:
• Synchronize with computer time sets date and time according to the computer’s clock. With this op tion, date and
time are set once and will not be updated automatically.
29
