Axis M7014 User Manual

AXIS M7014
System Options
• Authentication failed
SNMP v3 provid es encryption and secure passwords. To use traps with SNMP v3, an SNMP v3 management application is required.
To use SNMP v3, HTTPS must b e enabled, see HTTPS, on page 28. To enable SNMP v3, check the b ox and provide the initial user
password.
Note
The initial password can only be set once. If the p assword is lost, the Axis product must be reset to factory default, see
Reset to factory default s ettings, on page 38.
UPnP
TM
The Axis pro duct includes support for UPnP
TM
.UPnP
TM
is enabled by default and the product is automatically detected by operating
systems and clients that support this protocol.
UPnP
TM
can be disabled under System Options > Network > UPnP
TM
.
RTP/H.264
The RTP port range and multicast s ettings are configured under System Options > Network > RTP.
The RTP port range defines the range of ports from which the video ports are automatically selected. For multicast strea ms, only
certain IP addresses and port numbers should be used.
Select Always Multicast Video and/or Always Multicast Video to start multicast streaming without opening an RTSP session.
Bonjour
The A xis product includes support for Bonjour. Bonjo u r is enabled by default and the product is automatically detected by operating
systems and clients that support this protocol.
Bonjour can be disabled under System Options > Network > Bonjour.
Storage
SD card
The SD/SDHC memory card (not included) i s managed on the System Options > Storage page. Click SD card to open Storage
Management.
Mounting is done automatically when the card is inserted or when the product boots. SD cards are normally preformatted when
purchased, b ut if needed, click Form at to format the card.
Format an SD card so that it can be written to one of two availab le options — VFAT a nd ext4. During the formatting any previous
data stored on the disk will be lost. The recommended format is ext4, due to its resilience against data loss if the card is ejected
or if there is abrupt power loss. A third-party ext4 dr iver or application is also needed to access the file system from Windows.
Note that most SD cards are pre-formatted with vFAT when purchased. The Chec k Disk option is used to check for errors on the SD
card and only w orks for the file system ext4. The Repair option repairs the SD card of errors in the file system ext4. For vFAT file
system use a card reader or PC to perform card maintenance.
Note
To prevent corruption of recordings, the SD card should always be unmounted before remo val.
If the card’s status shows as failed, click Check disk to see if the problem can be found and then try Repair.
To avoid filling the card, it is recommended to remove recordings continuously. Under Recording Settings, select Remove recordings
older than and select the number of days or weeks.
To stop writing to the share and protect recordings from being removed, select Lock under Recording Settings.
34

Axis M7014 Specifications

General

Motion JPEG frame rate	15 fps
Maximum video resolution	720 x 576 pixels
PTZ control	Yes
Flash memory	128 MB
Image settings	Brightness, Color, Compression, Contrast, Mirroring, Privacy mask, Rotation
Internal memory	512 MB
Angle of rotation	270 °
Built-in processor	ARTPEC-4
Security algorithms	802.1x RADIUS
Supported network protocols	IPv4/v6, HTTP, HTTPS, IEEE 802.1X QoS 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Copper ethernet cabling technology	100BASE-TX, 10BASE-T
BNC input ports	4
I/O terminal ports	-
Ethernet LAN (RJ-45) ports	1
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 80 %
Power requirements	8-20 V DC
Power consumption (typical)	7 W
Certification	EN 55022 B, EN 61000-3-2, EN 61000-3-3, EN 55024, EN61000-6-1, EN61000-6-2, EN 60950-1, C-tick AS/NZS CISPR 22, FCC Part 15 B B, ICES-003 B, VCCI B, KCC B, UL/IEC/EN 60950-1

Weight and Dimensions

Weight	570 g
Dimensions (WxDxH)	172 x 109 x 37 mm
