31
AXOR Industries Service Manual MiniMagnum
TM
ver.1 rev.05/'15
2.16 Emulated encoder outputs connection
EMULATED ENCODER OUTPUTS connection
CN-GND
A+
A-
B+
B-
Z+
Z-
M2
R
1
2
3
4
5
6
CN
R
R
RS485
RS485
RS485
PGND
+5V
7
MiniMagnum
TM
CN-GND
A+
B+
Z+
M2
1
2
3
4
5
6
CN
PGND
+5V
7
MiniMagnum
TM
LINE RECEIVER CN inputs
COMMON MODE CN inputs
Note: We suggest connecting the shield on both sides: drive side, follow the indications illustrated on
paragraph 2.6.
