AXOR Industries Service Manual MiniMagnum
TM
ver.1 rev.05/'15
Index
A
Alarms 43
analog common mode input (TPRC) 7, 10, 30
analog differential or common mode inputs (+/-Vref) 7, 10, 30
Analog outputs 7, 10, 29
Auxiliary supply +24Vdc 24
B
Braking Resistance 10
C
Cables 19
Canbus connection 36
Conformity 47
Connection to earth 20
Connection to ground 20
D
Digital inputs 7, 10, 28
Digital output 7, 10, 29
Display 7, 42
Disposal 14
E
EMI lter 8
emulated encoder outputs 7, 31
encoder connection 33
Environmental conditions 18
equipment 8
Example of base connection 23
Expansion cards 8
External Protections 10
G
General view 9
H
Holding brake 8
I
installation procedure 22
K
KeyPad 7
